Item | Specifications | |
WIFI Antenna MIMO | Frequency Range | 2400~2483.5MHz/4900~5925MHz |
V.S.W.R | <2.0 | |
Polarization | Linear | |
Gain | 3dBi(Typ.) | |
Impedance | 50Ω | |
Mechanical | Cable | RG174 or others |
Connector | SMA or others | |
Radome Material | ABS | |
Mounting Method | Magnet/Adhesive | |
Environmental | Operating Temperature | -40℃~+85℃ |
Relative Humidity | Up to 95% | |
Ingress Protection | IP66 | |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
Environmentally Friendly | ROHS Compliant | |
