Item | Specifications | |
Antenna | Frequency | GPS L1/L2/L5 GLONASS G1/G2/G3 COMPASS B1/B2/B3/B1C/B2a/B2b Galileo E1/E2/E5a/E5b/E6 L-Band IRNSS L1/L5 |
Polarization | RHCP | |
Axial Ratio | ≤3dB | |
V.S.W.R | ≤2.0 | |
Peak Gain | ≥7dBi | |
Impedance | 50Ω | |
Phase Center Error | ±1.5mm | |
Horizontal coverage angle | 360° | |
LNA | Gain | 45±2dB |
Noise Figure | ≤2dB | |
Passband fluctuation | ±1.5dB | |
Supply Voltage | 3~16V DC | |
Current Consumption | ≤60mA | |
P1dB | ≥0dBm | |
V.S.W.R | ≤2.0 | |
Mechanical | Connector | TNC-K |
Dimension | Φ380*300mm | |
Environmental | Operating Temperature | -40℃~+85℃ |
Storage temperature | -55℃~+85℃ | |
Relative Humidity | Up to 95% (Non condensing) |
