Item | Specifications | |
Antenna | Frequency | 1575.42±3MHz |
Band Width | ≥10MHz | |
Polarization | RHCP | |
Gain | 3dBic(Zenith) | |
V.S.W.R | <1.5 | |
Impedance | 50Ω | |
LNA | Gain | 28±2dB |
Noise Figure | ≤1.5 | |
Supply Voltage | 3~5V DC | |
Current Consumption | 20~35mA | |
V.S.W.R | <2.0 | |
Connector | SMA | |
Radome Material | PC | |
Mounting Method | Screw | |
Environmental | Operating Temperature | -40℃~+60℃ |
Relative Humidity | Up to 95% | |
Ingress Protection | IP65 | |
